I86FI Series – 86″ 4K Touchscreen Display

Part Number: I86FI Series
Category: Large Format Touchscreen Monitors
This touchscreen monitor adheres to TAA requirements, ensuring smooth integration and peak performance for uninterrupted 24/7 operation year-round.
  • 86-Inch Screen Size
  • 3840 x 2160 4K UHD Resolution
  • Interface: HDMI / DisplayPort (DP) / USB-C (Embedded Android)
  • Interface: HDMI / USB-C (Without Android OS)
  • Intel OPS Slot for All Models / Android OS
  • 450 nits High Brightness
  • 2-year Extended Warranty Plan Available
MODEL
Part Number I86FI-4L0IT0 I86FI-4LRIT0 I86FI-4LPIT0 I86FI-4NPYT0 I86FI-4NRYT0
DISPLAY
Screen Size 75"
Resolution 3840 x 2160
Active Area 1895.04 (H) x 1065.96 (V)
Viewing Angle 178° / 178°
Response Time 5ms
Brightness 450cd/m²
Aspect Ratio 16 : 9
Contrast Ratio 1200 : 1
Color Depth 1.07B
Brightness LED
AUDIO
Speakers 10W x 10W (Optional 20Wx20W 2.1 Deep Bass Speaker)
INTERFACE
Ports HDMI x2, Audio x1, USB2.0 x1, USB3.0 x1, Touch USB x1, USB Out x1 HDMI x2, DP x1, USB-C x1
TOUCH TECHNOLOGY
Type / Point N/A IR Touch / 40-Point PCAP Touch / 40-Point IR Touch / 40-Point
FEATURES
OPS Slot Yes
OS Compatibility Win XP/ Win 7/ Win 8/ Win 10/ Android/ Mac
OS (Optional) Windows® System
SYSTEM
CPU N/A Quad-core A73 / A53+G52x8GPU 2.28GHz
WiFi N/A 2.4G&5G 802.11ax, WIFI 6
RAM/Storage N/A 8G/64G
OS N/A Android 14.0
CABINET
Color/Material Black/Metal Housing
POWER
Rating AC 100V~240V, 50/60Hz
TEMPERATURE
Operating/Storage 32° F ~ 104° F (0° C ~ 40° C) / -4° F ~ 104° F (-20° C ~ 40° C)
HUMIDITY
Operating/Storage 10%~80% / 5%~95%
DIMENSIONS
Inch / Millimeter 76.50(W)x43.86(H)x3.45(D) / 1943.24(W)x1114.16(H)x87.80(D)
VESA™
Mount Size (mm) 800 x 600
REGULATION
Certifica􀆟on CE / FCC
COMPLIANT
TAA Compliant Yes
product description
Technological advances and price decreases have significantly expanded the market for large 4K touchscreen displays. These innovative designs, featuring 4K displays of 32 inches and above, are creatingng new opportunities in digital signage, corporate webinars, and infotainment. Feel free to inquire about our large touchscreen LCDs or engage us with your latest solution project, and let our engineers position you for some thing big.



download data sheet



product dimension
