IR55BI – 55″ 4K UHD IR Touchscreen w/ Built-In Android OS

Part Number: IR55BI-O3-45I0D
Category: Large Format Touch Monitors

GVision 55″ 4K UHD digital signage interactive IR touchscreen monitor with built-in Android operating system create an intuitive interface to operate without PC required. IR touchscreen features wireless collaboration with cross-platform devices in the classroom. It is indeed an essential part for teaching and learning environment.
  • 4K UHD, 55-Inch, 3840 x 2160 Resolution
  • 32-Point Infrared IR Touchscreen
  • Video Signal: HDMI / DisplayPort (DP) / VGA
  • Built-In ANDROID Operating System
  • RJ45 LAN Input / Output for the Network
  • Interactive Annotation Tools: Whiteboard
  • SPDIF Optical Audio, Built-In Speakers
  • Window, Mac, Android, Linux, Chrome Touch Compatibility
MODEL
Part Number IR55BI-O3-45I0D
DISPLAY
Screen Size 55"
Resolution 3840 x 2160
Backlight Direct LED
Aspect Ratio 16 : 9
Viewing Angle 178° / 178°
Response Time 6ms
Brightness 450 cd/m²
Contrast Ratio 5000 : 1
INTERFACE
Video (Digital) Input HDMI 2.0 x 3 / DP 1.2 x 1 / USB-C 3.1 Gen2 x 1
Video (Analogue) Input VGA x 1 / AV x 1 / YPbPr x 1
RJ45 In / Out 1 / 1
Media (Android) Input USB 2.0 A-type x 1 / SD card Slot x 1
Media Input USB 3.0 A-type x 3 / USB-C 3.1 Gen2 x 1
RS232C In / Out 1 / 1
Audio Input Audio in (3.5mm) x 1 / Mic (3.5mm) x 1
Video (Digital) Output HDMI 2.0 x 1
Audio Output SPDIF Optical x 1 / Audio Out (3.5mm) x 1
Touch Output USB2.0 B-type x 3 / USB-C 3.1 Gen2 x 1
TOUCH TECHNOLOGY
Type High Precision and Lower Z-axis 32pt IR touch
Tempered Glass Anti-glare 4mm
OS Compatibility Win 10/8/7: 32pt / Win XP: 1pt / Mac: 1pt / Android: 16pt / Linux: 1pt / Chrome:1pt
CABINET
Material Metal
POWER
Android 8.0
CPU Dual Core A73+ Dual Core A53
RAM / ROM 4GB / 32GB
AUDIO
Speakers 16W x 2
POWER
Consumption AC100 ~ 240V 50/60Hz
TEMPERATURE
Operating 32° F ~ 104° F (0° C ~ 40° C)
HUMIDITY
Operating 20% ~ 80%
product description
These innovative designs, comprised of 55” 4K UHD IR touchscreen monitors with built-in Android OS, are creating opportunities in digital signage, corporate webinars and infotainment. Feel free to inquire about our large touch screen LCDs or engage us with your latest solution project and let our engineers position you for something big.
55-inch 4K UHD IR touchscreen



download data sheet



interactive innovation tool
It support interface to operate without PC required and features wireless collaboration with cross-platform devices in the classroom.
55-inch 4K UHD IR touchscreen
Annotation Tools for drawing and text tools are used to draw attention to content. This can be used on any content item where they appear, such as a whiteboard.



multi ports
55-inch 4K UHD IR touchscreen
