| MODEL | |
| Part Number | VW49CD-OD-40003 |
| DISPLAY | |
| Screen Size | 49" |
| Resolution | 1920 x 1080 |
| Bezel to Bezel Width | 3.5mm (2.25mm L/T, 1.25mm R/B) |
| Backlight Unit | LED |
| Aspect Ratio | 16 : 9 |
| Contrast Ratio | 1300 : 1 |
| Viewing Angle | 178° / 178° |
| Brightness | 450 Nit |
| LCD Technology | Commercial Grade IPS |
| Color | 1,06 billion color |
| INTERFACE | |
| HDMI In / Out | 1 / 1 |
| Display Port In | 1 |
| RS-232C In / Out | 1 / 1 |
| FEATURES | |
| Max. Daisy Chain | 10 x 10 |
| Built-In Processor | Yes |
| Auto Pixel Shift | Yes |
| White Balance | Yes |
| Cooling | Passive |
| Temperature Sensor | Yes |
| CABINET | |
| Material | Metal |
| POWER | |
| Consumption | < 220W |
| BTU: 751 | |
| Electrical Ratings | AC 100V ~ 240V, 50/60Hz |
| TEMPERATURE | |
| Operating | 32° F ~ 122° F (0° C ~ 50° C) |
| Storage | -4° F ~ 140° F (-20° C ~ 60° C) |
| HUMIDITY | |
| Operating | 20% ~ 80% |
| Storage | 10% ~ 90% |
| DIMENSIONS (WxHxD) | |
| Inch (in) | 42.4 x 23.9 x 4.1 |
| Millimeter (mm) | 1076.96 x 607.06 x 104.14 |
| WEIGHT | |
| Net Weight | 68.3 lbs (31kg) |
| VESA™ | |
| Mount Holes (mm) | 600 x 400 |
| MOUNT OPTION | |
| Custom Mount | VW-S (Scissor), VW-SD (Swing Door), VW-FS (Floor Stand), VW-C (Custom Design) |
VW49CD – 1.2mm Super Slim Bezel Video Wall Monitor
49″ 1.2mm super slim bezel provides a complete video wall systems that’s ideal for command & control centers, offices, shopping malls, stadiums, concert halls, and public transportation.
- 49 Inch, 1920 x 1080 Full HD Resolution
- 1.2mm Super Slim Bezel
- LED Backlight Unit
- Built-In Video Processor for Daisy Chain
- Display 4K Content Over 2 x 2 Video Wall
- Configurable Up To 10 x 10 Screens
- Support HDMI, Display Port, and RS232C Input Interface
- Design for 24 / 7 / 365 Operation
- Scissor, Swing Door, Floor Stand, Custom Design Mount
product description
GVision’s 49″ 1080p Full HD video wall monitors feature the 1.2mm super slim bezels in the industry, which are designed for 24/7 operation. Combined with our standard or custom mounting system and our PC-based video controller, GVision provides a complete video wall system that’s ideal for command & control centers, offices, shopping malls, stadiums, concert halls, and public transportation.
download documents
advantages
COLOR CALIBRATION
Factory tune to manage brightness and color uniformity conveniently with Color Calibration Suite software probe sensor hardware
DISPLAY 4K CONTENTS
GVision’s video wall monitors utilizing the built-in image processor, 4K content can be displayed across 4 monitors by daisy-chaining the HDMI inputs / outputs. The number of pixels distributed across the 4 HD monitors is equal to the number of pixels in 1 UHD monitor.
SUPER SLIM BEZEL
Full HD 1.2mm ULTRA NARROW BEZEL IPS Panel with Auto Power & Source Recovery.
OVERHEATING PROTECTION
The high temperature such as internal environment, long time use, and multiple connections of various units, Overheating Protection prevents increase of temperature for safety. Warning message and automatic power off at certain temperature.
interface and OSD
product dimension
video wall CONTROLLER
VW-CG SERIES
The GVision CG Series Video Wall Controller comes custom configured using our capture cards with up to 8 HDMI ports per card, The unit has a maximum of 10 configurable slots that can be used offering a mix of up to 80 Input & Output HDMI Ports.
video wall mount
MOUNT AND ACCESSORY
Video wall mounting options include standard wall mounts, scissor mounts, swing door mounts, floor stands and pedestal mounts. In addition, GVision can provide custom mounting, designed to fit your exact specifications.
