19" Rear Mount Touchscreen Monitor

R19ZH – 19″ Rear Mount PCAP Touchscreen Monitor

Part Number: R19ZH-OV-45P0
Category: Rear Mount Touch Monitor

GVision R19ZH is 19″ rear mount projected capacitive touch monitor. 10-point multi-touch with seamless flat bezel. Easy to clean (water and dust resistant).

19-Inch Screen Size
1280 x 1024 Resolution
Video Inputs: HDMI / VGA / DVI
250 nits Brightness
Projected Capacitive (PCAP) 10-Points Touch
Zero Pressure Touch Activation
IP65 on the Front (Option)
LED Backlight Unit Monitor
3-Year Warranty

MODEL
Part Number	R19ZH-OV-45P0
DISPLAY
Screen Size	19"
Resolution	1280 x 1024
Backlight Unit	LED
Aspect Ratio	5 : 4
Viewing Angle	170° / 160°
Brightness	250 nit
Color	16.7 Million
Contrast Ratio	1000 : 1
Response Time	5ms
INTERFACE
HDMI	1
DVI	1
VGA (15 Pin D-Sub)	1
USB Type-B	1
TOUCH TECHNOLOGY
Type	Projected Capacitance (PCAP)
Points	10-Points
Support OS	Window, Linux
CABINET
Material	Metal
Color	Black
POWER
Consumption	< 20W
Electrical Ratings	DC12V / 5A (AC 100V ~ 240V, 50/60Hz)
TEMPERATURE
Operating	32° F ~ 104° F (0° C ~ 40° C)
Storage	-4° F ~ 140° F (-20° C ~ 60° C)
Humidity	10 ~ 85%
DIMENSIONS (WxHxD)
Inch (in)	17.2 x 14.3 x 1.8
Millimeter (mm)	438.6 x 363.7 x 47.0
WEIGHT
Unit Weight	11.0 lbs (5.0 kg)
COMPLIANT
Certification	CE / FCC
VESA™
Mount Size (mm)	100 x 100

product description

GVision R19ZH is a 19″ rear mount projected capacitive touch monitor. 10-point multi-touch with the seamless flat bezel. R19ZH is purpose-built for system builders who require a rugged and durable touch screen solution that can easily be integrated into any embedded application. It is completely sealed to protect against the elements, which means it can be used either inside or out, and in high-traffic public-facing applications.
