10.1" Touchscreen POE Monitor

PoE – 10.1″ PCAP Touchscreen & Android OS POE Monitor

Part Number: PE10ZJ-OS-45P0D
Category: PoE Monitors

GVision 10.1″ Touchscreen POE Monitor with built-in Android 10 is specially designed to operate 24/7 and is equipped with optional PoE, allowing more flexibility to meet your needs.

10.1-Inch Size / 1280 x 800 Resolution
Gigabit Ethernet (1000BASE-T) Port for both Power & Data
Built-In ANDROID 10 Operating System
10-Point PCAP Touch
Interface: Mini HDMI Out / USB Type-C / RJ45 / USB2.0 / USB3.0
24 / 7 Operation Design
3-Year Warranty

**PoE Injector not Included

MODEL
Part Number	PE10ZJ-OS-45P0D
DISPLAY
Screen Size	10.1"
Resolution	1280 x 800
Backlight Unit	LED
Aspect Ratio	16 : 10
Viewing Angle	170° / 170°
Brightness	350 Nit
Color	16.7 Million
Contrast Ratio	800 : 1
Response Time	25ms
INTERFACE
Mini HDMI Out	1
RJ45 (PoE)	1
USB 2.0 / 3.0	1 / 1
USB Type-C	1
Earphone Out	1
TOUCH TECHNOLOGY
Type	PCAP
Point	10-Point
Surface Hardness	7H
SYSTEM
OS	Android 10
Chipset	Rockchip RK3399, Dual-Core Cortex-A72 and Quad-Core Cortex-A53
RAM / ROM	4GB / 32GB Flash
Network	WiFi
CABINET
CABINET	Metal
POWER
Consumption	<15W
Type Input	RJ45 PoE
TEMPERATURE
Operating	32° F ~ 122° F (0° C ~ 50° C)
Storage	-4° F ~ 140° F (-20° C ~ 60° C)
Humidity	10 ~ 85%
DIMENSIONS (WxHxD)
Inch (in)	9.83 x 6.62 x 1.18
Millimeter (mm)	249.8 x 168.4 x 30.0
WEIGHT
Unit Weight	7.7 lbs (3.5 kg)
VESA™
Mount Size (mm)	75 x 75
INCLUDE
Accessories	Power cable and prower adaptor

product description

GVision 10.1″ Touchscreen POE Monitor is an All-In-One Monitor with built-in Android 10, specially designed to operate 24/7. It’s equipped with Rockchip’s RK3399, which is a low-power, high-performance processor with integrated Dual-core Coretex-A72 and Quad-core Cortex-A53. The optional PoE, 10 Point PCAP Touch Screen, and 350 nits brightness combined with the powerful processor will allow it to fit various applications and your needs.
