15" Desktop PCAP Touchscreen Monitor

D15ZX – 15″ Desktop PCAP Touchscreen Monitor

Part Number: D15ZX-AV-K5P0
Category: Desktop Touchscreen Monitors

GVision desktop touchscreen displays a 15-inch touchscreen monitor and performs 10-point multi-touch of the projected capacitive PCAP screen.

15-Inch Screen Size
1024 x 768 Resolution
Video Inputs: HDMI / VGA / DVI
Zero Bezel Touchscreen
Projected Capacitive (PCAP) 10-Points Touch
Zero Pressure Touch Activation
IP65 on the Front (Option)
LED Backlight Unit Monitor
3-Year Warranty

MODEL
Part Number	D15ZX-AV-K5P0
DISPLAY
Screen Size	15 In
Resolution	1024 x 768
Backlight Unit	LED
Aspect Ratio	4 : 3
Viewing Angle	170° / 170°
Response Time	35ms
Brightness	270cd/m²
Contrast Ratio	1500 : 1
Display Area	304.1 (H) x 228.1 (V)
Color	16.7 M
AUDIO
Speaker	Option
INTERFACE
HDMI	1
DVI	1
VGA (15-Pin)	1
USB-B Type	1
TOUCH TECHNOLOGY
Type	Projected Capacitive PCAP
Points	10-Points
Interface	USB-B type
CABINET
Material	Plastic Frame / Metal Housing
Color	Silver Frame / Black Housing
POWER
Consumption	16W
Input Voltage	12V DC/5% (AC 100V ~ 240V, 50/60Hz)
TEMPERATURE
Operating	32° F ~ 104° F (0° C ~ 40° C)
Storage	-4° F ~ 140° F (-20° C ~ 60° C)
HUMIDITY
Operating	10% ~ 80%
DIMENSIONS (WxHxD)
Inch (in)	14.3 x 13.7 x 8.7
Millimeter (mm)	362.4 x 348.4 x 220.0
WEIGHT
Net Weight	11 lbs (5.2 kg)
REGULATION
Certification	CE / FCC
VESA™
Mount Holes (mm)	100 x 100

product description

GVision desktop touchscreen of the D15ZX is a point-of-sale (POS) touch monitor that displays a 15-inch touchscreen to perform 10-point multi touch technology on a projected capacitive PCAP screen.
