|Pixel Configuration||SMD LED|
|Panel Resolution||240 x 135|
|Refresh Rate (Hz)||1920 / 2880 / 3840|
|Gray Level (bit)||12 / 14 / 16|
|Color Temperature (K)||2000 < TC < 10000 adjustable|
|Contrast Ratio||8000 : 1|
|Viewing Angle (H / V)||160° / 160°|
|Brightness Adjustment||Programmable / Auto / ManuaI|
|Color Calibration||Brightness and Chroma Calibration|
|Working Voltage||AC 100V ~ 240V, 50/60Hz|
|Power Consumption||450W (Max.) / 113W (Avg.)|
|Storage||-4° F ~ 122° F (-20° C ~ 50° C)|
|Inch (in)||24.2 x 13.5 x l.5|
|Millimeter (mm)||610.3 x 343.1 x 39.2|
|Per Uni||14.7 lbs (6.7 Kg)|
L2D – 2.5mm Pixel Pitch LED Tile Display Monitor
GVision offers a complete range of LED tile display technology for indoor application. This L2D-0DDA-420 LED is 2.5mm pixel Pitch perform 240 x 135 high resolution and high brightness of 600 nits LED displays.
- 240 x 135 Panel Size Resolution
- 2.5mm Pixel Pitch
- 600 nits High Brightness
- Brightness and Chroma Color Calibration
- Versatile and Efficient Installation
- Die-Casting Aluminum Cabinet Material
- User-Friendly Front Maintenance
- Design to Operate Long Lifespan
- 3-Year Warranty
GVision offers a complete range of LED tile display technology for studios, control rooms, office conference, professional AV and other venues. This L2D-0DDA-420 LED is fine-pitch screen with a 2.5mm pixel Pitch perform 240 x 135 screen resolution in which designed for indoor application. This product is available to meet the needs of those looking for high resolution and high brightness of 600 nits LED displays.
download data sheet
EXCELLENT DISPLAY EFFECT
- High Flatness
- High Contrast Ratio (Intelligent Powder Coding)
- Low Brightness and High Gray Level
- NTSC Broadcasting Level Color Gamut
- Brightness and Chroma Calibration
- 160° Wide Viewing Angle
Through HDR, LED display can present pictures in a more delicate way to bring up more details. Our LED adopts the industry’s top-level control system and fully supports the latest HDR function, to achieve unrivaled display effect to perfect restore the real color.
Light Weight Design
Thickness is only 39mm 50% slimmer than traditional panel. Wall mounted thickness is only 64mm save conventional space. Light weight design.
Components like modules, power supply, system card can be maintained from the front without rear space. Module removal takes only 1 s before dealing with potential failures.
